Publication 2098-IN005C-EN-P — March 2008
Commissioning Your Ultra3000 Drive
95
4. Observe the module status indicator.
5. Observe the network status indicator.
For further commissioning procedures, refer to the following table for
procedures.
Ultra3000 Drive Configuration Procedures
Refer to the Ultra3000 with DeviceNet Reference Manual, publication
drives using DeviceNet.
Module Status Indicator
Status
Do This
Steady green
The drive is ready.
Go to step 5.
Not steady green
The drive is faulted.
Go to DeviceNet Module Status
Indicator on page 109.
Network Status Indicator Status
Do This
Off
Establishing communication
with network.
Wait for flashing or steady
green.
Flashing or steady green
Communication is ready.
Go to step .
Not flashing or steady green The drive is faulted.
Go to DeviceNet Network Status
Indicator on page 109.
Procedure
Page
Understanding the Workspace and Drive Branches
Test Your Motor (non-indexing move)
Test Your Motor (indexing move)
