Publication 2098-IN005C-EN-P — March 2008
Interconnect Diagrams 129
In this example, the 2098-DSD-030x-xx Ultra3000 drive is wired to the
120V ac control string.
120V ac Single-phase Control String Example
ATTENTION
Implementation of safety circuits and risk assessment is the
responsibility of the machine builder. Please reference
international standards EN1050 and EN954 estimation and
safety performance categories. For more information refer to
Understanding the Machinery Directive, publication SHB-900.
CN1
120V ac
50/60 Hz
STOP
START
CR1
CR1
CR1
M1
Refer to Attention statement above
CR2
N.O. Relay Output+
N.O. Relay Output-
43
44
CR2
24V dc
Single-phase
AC Line 50/60 Hz
M1
Fuse
Block
L1
L2/N
L1 Aux
L2/N Aux
Ultra3000
Drive
U
V
W
+
-
L1
L2/N
L1
AUX
L2/N
AUX
1
2
3
Motor
DC Bus
100-240 VAC
50/60 Hz
Internal
External Shunt
TB1
TB2
Note 22
