Rockwell Automation 2090 Ultra3000 Servo Drives Integration Manual User Manual
Page 92

Publication 2098-IN005C-EN-P — March 2008
92
Commissioning Your Ultra3000 Drive
Use this figure to locate the front panel connections on the
Ultra3000-DN 460V drives (3 kW, 5 kW, 10 kW, 15 kW, and 22 kW).
Front Panel Connections for 2098-DSD-HVxxx-DN and
2098-DSD-HVxxxX-DN Drives
For CN1, CN2, and CN3 connector pin-out information, refer to the
Ultra3000 Digital Servo Drives Installation Manual, publication
2098-IN003.
W
V
U
+
-
L3
L2
L1
L1
AUX
L2
AUX
Motor
DC Bus
230-480 V
A
C
50/60 Hz
Internal
External Shunt
1
2
3
Can_H
V+
TB2
DANGER
DANGER
Hazardous voltage
exists after power down.
TB1
500kB
250kB
125kB
AUTO
PGM
V-
Can_L
Shield
(00-63, PGM)
,ALE?ANet
Pin 11
Pin 6
Pin 15
Pin 1
Pin 10
Pin 5
Pin 30
Pin 44
Pin 1
Pin 15
Pin 16
Pin 31
Pin 6
Pin 9
Pin 1
Pin 5
AC Input Power
Connections
Motor Power
Connections
Passive Shunt
Resistor Connections
Seven-segment
Status Indicator
Logic Power Indicator
CN3 9-pin
Serial Port
Connector
CN2 15-pin
Motor Feedback
Connector
CN1 44-pin
User I/O
Connector
DeviceNet Interface
Connector
Node Address Switches
Data Rate Switch
Module Status Indicator
Network Status Indicator
Motor Power
Cable Shield Clamp
9-pin CN3
Serial Connector
15-pin CN2
Feedback Connector
44-pin CN1
I/O Connector
