Component Definition and Maintenance
Chapter 3
Clean the PowerCage with a general purpose household cleaner. Do not spray
onto the PowerCage as it promotes electrical tracking. Apply the cleaner to a
paper towel and wipe the surface of the PowerCage where you will apply the
gasket. Liberally spray the surface with distilled water, then wipe dry with a clean
paper towel.
Apply a thin bead of Loctite 454 adhesive to the PowerCage surface in a zigzag
pattern using the original nozzle size. Use the tip to spread the adhesive around to
cover at least 50% of the area. There should be sufficient quantity of adhesive to
remain wet long enough for the gasket to be applied. The adhesive uses the
moisture in the air as it cures. The higher the humidity the faster the adhesive will
cure.
Position the gaskets ensuring the gasket is oriented correctly. Center the gasket
over the opening for the heat sinks with the narrow end positioned closest to the
test points. Apply the porous surface of the gasket to the PowerCage. The gasket
will bond almost immediately. Apply some pressure to the gasket for 15...30
seconds.
After all the gaskets have been placed check to see that the gasket has bonded
properly. Repair any loose areas.
Removing the PowerCage
1.
Ensure there is no power to the equipment.
2.
Before removing the PowerCage, remove all the components located
within the PowerCage to avoid any damage to the components. Consult
the required sections to remove clamping pressure, as well as remove the
SGCT or SCR, circuit boards, and thermal sensor.
3.
Remove the 13 mm bolts in the two flanges that connect the heat sink to
the PowerCage, then remove the heat sink from the PowerCage. This
reduces the PowerCage weight for easier handling.
IMPORTANT
This adhesive will bond anything quickly, including fingers!
ATTENTION: To prevent electrical shock, disconnect the main power before
working on the drive. Verify that all circuits are voltage-free using a hot stick or
appropriate voltage-measuring device. Failure to do so may result in injury or
death.
ATTENTION: Static charges can destroy or damage the SCR and SCR SPGD
board. Properly ground yourself before removing the replacement SCR and SCR
SPGD board from the protective anti-static bag. Using damaged circuit boards
may also damage related components. Use a grounding wrist strap for handling
sensitive circuit boards.
