Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 27
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
27
Component Definition and Maintenance
Chapter 3
Figure 19 - Cabling cabinet for AFE rectifier (heat pipe model)
Grounding Network (For use
with Isolation Transformer)
or
Ground Filter (For use with
Line Reactor)
Surge Arresters
Voltage Sensing Boards
Line Terminals
Current Transformers
Zero Sequence Current
Transformer (used with
Line Reactor)
Motor Terminals
Hall Effect Current
Sensors
