148

Rockwell Automation Publication 7000-UM202B-EN-P - June 2014

Chapter 3

Component Definition and Maintenance

ACB-TP40

Vnn

CMC Neutral Voltage, VNN

ACB-TP41

Inn

CMC Neutral current, INN

ACB-TP42

Ignd

Ground Fault current, GFCT

ACB-TP43

Vspr

Spare channel for inputs

ACB-TP44

Vmtrp

Motor Over Voltage Detection set point

ACB-TP45

A+

Encoder A+ input

ACB-TP46

B+

Encoder B+ input

ACB-TP47

Z+

Encoder Z+ input

ACB-TP48

A-

Encoder A-input

ACB-TP49

B-

Encoder B- input

ACB-TP50

Z-

Encoder Z- input

Test points

Name

Description

ACB-TP51

CP1

Control Power monitoring for channel 1

ACB-TP52

CP2

Control Power monitoring for channel 2

ACB-TP53

CP3

Control Power monitoring for channel 3

ACB-TP54

CP4

Control Power monitoring for channel 4

ACB-TP55

Vltrp

AC Over Voltage Detection set point for 2UVW & 3UVW

ACB-TP56

AGND

Analog ground

ACB-TP57

AGND

Analog ground

ACB-TP58

AGND

Analog ground

ACB-TP59

AGND

Analog ground

ACB-TP60

+5V

+5V DC power supply

ACB-TP61

+15V

+15V DC power supply

ACB-TP62

-15V

-15V DC power supply

ACB-TP63

+24V

+24V DC power supply

ACB-TP64

-24V

-24V DC power supply

ACB-TP65

24VCOM

+/- 24V common

ACB-TP66

DGND

Digital ground

ACB-TP67

AGND

Analog ground

ACB-TP68

AP1

Analog Control Inputs, Air pressure input, AP1

ACB-TP69

AP0

Analog Control Inputs, Air pressure input, AP0

ACB-TP70

AIN1

Analog Control Input, AIN1

ACB-TP71

AIN2

Analog Control Input, AIN2

ACB-TP72

AIN0

Analog Control Input, AIN0

ACB-TP73

AIN3

Analog Control Input, AIN3

ACB-TP74

IPIS

Input Isolating Switch

ACB-TP75

IPCS

Input Contactor Status

ACB-TP76

IP

Input Contactor Command

ACB-TP77

OPIS

Output Isolating Switch

Test points

Name

Description
