Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 51
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
51
Component Definition and Maintenance
Chapter 3
Figure 36 - Converter cabinet (heat sink model, 2400V)
Isolated Gate Driver Power
Supplies (IGDPS)
Rectifier IGDPS not
required in drives with
SPS boards installed
Ground Bus
Inverter Modules
Differential Pressure
Sensor
Rectifier Modules
