Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 60
60
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
Chapter 3
Component Definition and Maintenance
Figure 47 - 6600V Six Device PowerCage (heat sink model)
Figure 48 - 6600V Six Device PowerCage (with SPS Boards installed)
Clamp Base
Matched Set
Three SGCTs
Matched Set
Three SGCTs
Clamp Head
Heat sink
Temperature Feedback Board
Module Housing
Clamp Base
Matched Set
Three SGCTs
Matched Set
Three SGCTs
Clamp Head
Heatsink
SPS Mounting Assembly with
Temperature Feedback Board
SPS Mounting Assembly without
Temperature Feedback Board
Module
Housing
