Page 92
92
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
Chapter 3
Component Definition and Maintenance
Figure 84 - Thermal sensor replacement (heat pipe model)
Air flow sensor plugs into
feed back circuit board
Air flow sensor
mounting bracket
Thermal sensor plugs
into feedback circuit
board
Temperature feedback
air flow circuit board
