Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 45
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
45
Component Definition and Maintenance
Chapter 3
Figure 33 - Hall Effect Current Sensor located within cabinet
Figure 34 - Hall Effect Current Sensor (detail)
Bus Bar
Hall Effect
Current Sensor
M10 Hardware
Base Hardware
Arrows must be
oriented properly
