Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 71
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
71
Component Definition and Maintenance
Chapter 3
Figure 59 - Replacing the SGCT
Figure 60 - Replacing the SGCT (if SPS board is installed)
SGCT captive screws
Clamp head block
Disc Springs
Inside nut for loosening and
applying load to assembly
DO NOT ADJUST outside nut
Clamp head block
SPS board mounting
assembly captive screws
SGCT captive screws
Inside nut for
loosening and
applying load to
assembly
DO NOT ADJUST outside nut
