Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 58
58
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
Chapter 3
Component Definition and Maintenance
Figure 43 - 2400V Two Device PowerCage (heat sink model)
Figure 44 - 2400V Two Device PowerCage (with SPS Boards installed)
Clamp Base
SGCTs
Heat sink
Module
Housing
Temperature
Feedback Board
Clamp Head
Clamp Base
Heat sink
Module Housing
SPS Board
Mounting
Assembly
without
Temperature
Feedback
Board
Clamp Head
SGCT
SPS Mounting Assembly with
Temperature Feedback Board
SGCT
