Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 30
30
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
Chapter 3
Component Definition and Maintenance
Figure 22 - AC line reactor cabinet with connection cabinet (heat sink model)
Line Filter
Capacitors
Zero Sequence
Current
Transformer
(if supplied)
Line
Reactor
Line
Terminals
Motor
Terminals
Motor Filter
Capacitors
