Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 61
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
61
Component Definition and Maintenance
Chapter 3
Figure 49 - 3300/4160V Four Device PowerCage (heat pipe model)
Heat Pipe Support Channel
Module Housing
Clamp Base
Matched Set
Two SGCTs
Temperature
Feedback Board
Matched Set
Two SGCTs
Clamp Head
Heat Pipe Assembly
