Important User Information

This document provides procedural information for managing daily or recurring
tasks involving the PowerFlex 7000 medium voltage “B” Frame drives (heat sink
and heat pipe models).

Who Should Use This Manual

This manual is intended for use by personnel familiar with medium voltage and
solid-state variable speed drive equipment. The manual contains material that
enables regular operation and maintenance of the drive system.

What Is Not in this Manual

This manual provides information specific to maintaining the PowerFlex 7000
“B” Frame drive. It does not include topics such as:

Physically transporting or siting the drive cabinetry

Installing or commissioning procedures

Dimensional and electrical drawings generated for each customer’s order

Spare parts lists compiled for each customer’s order

Please refer to the following documents for additional product detail or
instruction relating to PowerFlex 7000 “B” Frame drives:

Drive-specific Technical Data: additional troubleshooting, parameters,
and specification information for MV variable frequency drives
(

7000-TD002_-EN-P

)

Transportation and Handling Procedures: receiving and handling
instructions for Medium Voltage variable frequency drive and related
equipment (

7000-IN008_-EN-P

)

Installation Guide: detailed installation and pre-commissioning
procedures and information (

7000-IN007_-EN-P

)

Commissioning Guide: required procedures and checklists for Rockwell
Automation field service engineers (

7000-IN006_-EN-P

)

Operator Interface Guide: HMI Offering with Enhanced Functionality
(

7000-UM201_-EN-P

)

For drives equipped with the PanelView 550 HMI,
see

7000-UM151_-EN-P.

Rockwell Automation provides the site- and installation-specific electrical and
design information for each drive during the order process cycle. If they are not
available on site with the drive, contact Rockwell Automation.
