Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 53
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
53
Component Definition and Maintenance
Chapter 3
Figure 38 - Converter cabinet (heat sink model, 6600V version shown)
Differential Pressure
Sensor
Ground Bus
Isolated Gate Driver
Power Supplies
(IGDPS)
Rectifier IGDPS not
required in drives with
SPS boards installed
Rectifier Modules
Inverter Modules
