Drive processor module – Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 141
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
141
Component Definition and Maintenance
Chapter 3
Drive Processor Module
This board contains the control processors. It is responsible for all the drive
control processing and stores all of the parameters used for the drive control.
Figure 129 - Drive Processor Module (DPM)
Inverter
Gating
Signals
Rectifier
Gating
Signals
Secondary
Primary
Secondary
Primary
Test Points
Battery
HMI
Interface
Module
DPM DataPort
