Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 28
28
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
Chapter 3
Component Definition and Maintenance
Figure 20 - Cabling Cabinet for AFE Rectifier (6600V heat pipe model)
Surge Arrestors
Zero Sequence
Current
Transformer
Current Transformer
Grounding Filter (for
use with Line Reactor)
Hall Effect Current
Sensors
Voltage Sensing Boards
Motor Terminals
Line Terminals
