Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 129
Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
129
Component Definition and Maintenance
Chapter 3
Figure 115 - Location of AC/DC power supply on LV panel (heat pipe model)
Terminal / Connections Descriptions (Pioneer Power Supply)
The terminal connections are shown in
Figure 116 - Terminal locations on AC/DC (Pioneer) power supply
AC/DC Power Supply in LV
compartments above
converter section
Eart
h
Li
ne
Neu
tr
al
FRONT VIEW
TOP
VIEW
Single Phase Input
DC Outputs
Control
Signals
