Rockwell Automation Publication 7000-UM202B-EN-P - June 2014

113

Component Definition and Maintenance

Chapter 3

Figure 100 - DC Link/Fan cabinet with panel removed to show CMC (heat pipe model)

Fans

Common Mode
Choke
