Rockwell Automation 7000 PowerFlex Medium Voltage AC Drive (B Frame) - ForGe Control User Manual
Page 167

Rockwell Automation Publication 7000-UM202B-EN-P - June 2014
167
Component Definition and Maintenance
Chapter 3
TP35
CMD_14
OIB C, TX3 Firing Command Signal
TP36
DIAG_15
OIB C, RX4 Diagnostic Feedback
TP37
CMD_15
OIB C, TX4 Firing Command Signal
TP38
DIAG_16
OIB C, RX5 Diagnostic Feedback
TP39
CMD_16
OIB C, TX5 Firing Command Signal
TP40
DIAG_17
OIB C, RX6 Diagnostic Feedback
TP41
CMD_17
OIB C, TX6 Firing Command Signal
TP42
TFB_C
OIB C Temperature Feedback Signal – There is no provision in the drive for
the use of this signal, it is only provided for Rockwell internal testing.
TP43
GND
Ground Reference for TP30 – TP42
Test Point
Signal Name
Description
