Rockwell Automation 25-COMM-E2P PowerFlex 25-COMM-E2P Dual-Port EtherNet/IP Adapter User Manual
Page 78
78
Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013
Chapter 6
Using Explicit Messaging
Explanation of Request and Response Data for Read/Write Multiple
Messaging
The data structures in
Data Structures for Scattered Read Messages on page 79
and
Data Structures for Scattered Write Messages on page 80
use 16-bit words
and can accommodate up to 64 parameters in a single message. In the Response
Message, a parameter number with Bit 15 set indicates that the associated
parameter value field contains an error code (parameter number in response data
will be negative).
The PowerFlex 525 Adjustable Frequency AC Drive User Manual, publication
lists the data type for each parameter.
