142

Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013

Appendix C

EtherNet/IP Objects

DPI Device Object

Class Code

Services

Instances

The number of instances depends on the number of components in the device.
The total number of components can be read in Instance 0, Class Attribute 4.

Class Attributes

Hexadecimal

Decimal

0x92

146

Implemented for:

Service Code

Class

Instance

Service Name

0x0E

Yes

Yes

Get_Attribute_Single

0x10

Yes

Yes

Set_Attribute_Single

Instances (Hex.)

Instances (Dec.)

Single-Drive Mode

Multi-Drive Mode

0x0000...0x3FFF

0...16383

Instances 0...1023 in the drive

Instances 0...1023 in Drive 0

0x4000...0x43FF

16384...17407

Instances 0...1023 in the interface

(1)

(1) Interface is the current interface being used to access the information.

Instances 0...1023 in the interface

(1)

0x4400...0x47FF

17408...18431

DSI

Instances 0...1023 in Drive 1

0x4800...0x4BFF

18432...19455

Option

Instances 0...1023 in Drive 2

0x4C00...0x4FFF

19456...20479

Not supported

Instances 0...1023 in Drive 3

0x5000...0x53FF

20480...21503

Not supported

Instances 0...1023 in Drive 4

0x5400...0x57FF

21504...22527

Not supported

Instances 0...1023 in the Option

Attribute ID

Access Rule

Name

Data Type

Description

0

Get

Family Code

USINT

0x00 = DSI Peripheral
0x09 = Single Mode
0x0B = Multi-Drive Mode
0x1E = 25-COMM-X Option Module
0xFF = HIM

1

Get

Family Text

STRING[16]

Text identifying the device.

2

Set

Language Code

USINT

1 = English
2 = French
3 = Spanish
4 = Italian
5 = German
6 = Japanese
7 = Portuguese
8 = Chinese Simplified
9 = Reserved
10 = Reserved
11 = Korean
12 = Polish
13 = Reserved
14 = Turkish
15 = Czech
