Page 32
32
Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013
Chapter 3
Configuring the Adapter
2.
Set the value of
Device parameters 10 [Subnet Cfg 1] through
13 [Subnet Cfg 4]
to the desired value for the subnet mask.
3.
Reset the adapter; see
Resetting the Adapter on page 36
Setting a Gateway Address Using Parameters
1.
Verify that
Device parameter 04 [Net Addr Sel] is set to 1“Parameters”.
2.
Set the value of
Device parameters 14 [Gateway Cfg 1] through
17 [Gateway Cfg 4]
to the desired value for the gateway address.
3.
Reset the adapter by power cycling the drive.
Setting the Data Rate
By default, the adapter automatically detects the data (baud) rate and duplex
setting used on the network. If you need to set a specific data rate and duplex
setting, the value of
Device parameters 18 [Net Rate Cfg 1] determines the
Ethernet data rate and duplex setting that will be uses to communicate on the
adapter’s ENET1 network port. For definitions of data rate and duplex, see the
1.
Set the value of
Device parameter 18 [Net Rate Cfg 1] to the data rate at
which your network is operating.
255.255.255.0
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
192.168.1.1
[Gateway Cfg 1]
[Gateway Cfg 2]
[Gateway Cfg 3]
[Gateway Cfg 4]
Options
0 “Autodetect” (Default)
1 “10Mbps Full”
2 “10Mbps Half”
3 “100Mbps Full”
4 “100Mbps Half”
TIP
Auto detection of data rate and duplex works properly only if the
device (usually a switch) on the other end of the cable is also set to
automatically detect the data rate/duplex. If one device has the data
rate/duplex hard-coded, the other device must be hard-coded to the
same settings.
