Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013 27
Configuring the Adapter Chapter 3
Using the PowerFlex 4-Class
HIM to Access Parameters The PowerFlex 4-class HIM can be used to access parameters in the drive (see
basic steps shown below). It is recommended that you read through the steps for
your HIM before performing the sequence. For additional HIM information,
refer to the HIM Quick Reference card, publication
22HIM-QR001 .
To display the Host parameters, repeat steps 1 through 3 and select “PowerFlex
525” at step 3.
Setting the Adapter Node
Address When the Node Address switches (see Setting the Node Address Switches on
page 18 ) are set to a value other than 001...254 or 888, Device parameter 04 [Net
Addr Sel] determines the source for the adapter node address. By default, the
Node Address switches are set to 999 and Device parameter 04 [Net Addr Sel] is
set to 3 “DHCP”. This combination selects a DHCP server as the source for the
node address. To use a BOOTP or DHCP server to set the node address, see
Using a BOOTP or DHCP Server on page 28 . To use adapter parameters, see
Using Adapter Parameters on page 31 .
Step Key(s) Example Display
1. Power up the drive. Then connect the HIM
to the DSI port of the drive. The Parameters
tab for the drive will be displayed.
2. Press Sel until the DSEL tab is selected.
3. Select DSI Device in the DSEL tab if it is not
already selected using the Up Arrow or
Down Arrow.
Press Enter to select DSI Device.
4. Press the Up Arrow or Down Arrow to scroll
to 25-COMM-E2P.
Press Enter to reload the HIM to browse
only the Communication Adapter (25-
COMM-E2P) parameters.
Parameters
Groups
Linear List
Changed Params
DIAG PARAM DSEL MEM SEL
Sel Device Select
DSI Devices
DIAG PARAM DSEL MEM SEL
and
DSI Devices
PowerFlex 525
25-COMM-E2P
and
DSI Devices
PowerFlex 525
25-COMM-E2P
