130

Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013

Appendix C

EtherNet/IP Objects

Identity Object

Class Code

Services

Instances (Single-Drive)

Instances (Multi-Drive)

Class Attributes

Hexadecimal

Decimal

0x01

1

Implemented for:

Service Code

Class

Instance

Service Name

0x05

No

Yes

Reset

0x0E

Yes

Yes

Get_Attribute_Single

0x01

Yes

Yes

Get_Attribute_All

Instance

Description

0

Class

1

Host drive

2

DSI device

3

25-COMM-E2P

Instance

Description

0

Class

1

25-COMM-E2P

Attribute ID

Access Rule

Name

Data Type

Description

2

Get

Max Instance

UINT

Total number of instances
