Drive 0 control routines – Rockwell Automation 25-COMM-E2P PowerFlex 25-COMM-E2P Dual-Port EtherNet/IP Adapter User Manual
Page 105
Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013
105
Using Multi-Drive Mode
Chapter 7
Drive 0...4 Control Routines
The following Drive Control routines provide status information (Logic Status
and Feedback), control (Logic Command and Reference), and parameter read/
write for each of the respective drives:
Control Routine
See page...
Drive 0
Drive 1
Drive 2
Drive 3
Drive 4
