Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013

Appendix C

EtherNet/IP Objects

3

Set

Configuration Control

UDINT

Bit | Value
0…3 = Startup configuration

0 = Use configuration saved in NVS
1 = Obtain configuration using BOOTP
2 = Obtain configuration using DHCP
3…15 = Reserved

4 = DNS Enabled (resolves host names by query to DNS server)
5…31 = Reserved

4

Get

Physical Link Object

STRUCT of:

UINT
Padded EPATH

Path size
Path

5

Get

Interface Configuration

STRUCT of:

UDINT
UDINT
UDINT
UDINT
UDINT
STRING

Adapter IP address
Adapter subnet mask
Adapter gateway address
Primary name server
Secondary name server
Default domain name

6

Set

Host Name

STRING

Host name when using DHCP

10

Set

Select ACD

BOOL

Activates the use of ACD

11

Set

Last Conflict Detected

STRUCT of:

USINT
USINT[6]
USINT[28]

ACD Activity
Remote MAC
ARP PDU

Attribute ID

Access Rule

Name

Data Type

Description
