Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013 121
Troubleshooting Chapter 8
9 DSI Removed The adapter detected that the DSI device was disconnected.
10 DSI Logon The adapter has established communications with the DSI device.
11 DSI Timeout The adapter has lost communications with the DSI device.
12 DSI Brand Flt The brand of the DSI device is different from the adapter.
13 Host 0 Logon The adapter has established communications with host 0.
14 Host 1 Logon The adapter has established communications with host 1 (multi-drive mode).
15 Host 2 Logon The adapter has established communications with host 2 (multi-drive mode).
16 Host 3 Logon The adapter has established communications with host 3 (multi-drive mode).
17 Host 4 Logon The adapter has established communications with host 4 (multi-drive mode).
18 Host 0 Timeout The adapter has lost communications with host 0.
19 Host 1 Timeout The adapter has lost communications with host 1 (multi-drive mode).
20 Host 2 Timeout The adapter has lost communications with host 2 (multi-drive mode).
21 Host 3 Timeout The adapter has lost communications with host 3 (multi-drive mode).
22 Host 4 Timeout The adapter has lost communications with host 4 (multi-drive mode).
23 Host 0 Brand Flt The brand of host 0 is different from the adapter.
24 Host 1 Brand Flt The brand of host 1 is different from the adapter (multi-drive mode).
25 Host 2 Brand Flt The brand of host 2 is different from the adapter (multi-drive mode).
26 Host 3 Brand Flt The brand of host 3 is different from the adapter (multi-drive mode).
27 Host 4 Brand Flt The brand of host 4 is different from the adapter (multi-drive mode).
28...30 Reserved –
Network Events
31 Net Dup Address The adapter uses the same IP address as another device on the network.
32 Net Comm Fault The adapter detected a communications fault on the network and has performed the
“Comm Flt” action specified by the user.
33 Net Sent Reset The adapter received a reset from the network.
34 Net IO Close An I/O connection from the network to the adapter was closed.
35 Net Idle Fault The adapter detected a network idle condition on the network and has performed the
“Idle Flt” action specified by the user.
36 Net IO Open An I/O connection from the network to the adapter has been opened.
37 Net IO Timeout An I/O connection from the network to the adapter has timed out.
38 Reserved –
39 PCCC IO Close The device sending PCCC Control messages to the adapter has set the PCCC Control
Timeout to zero.
40 PCCC IO Open The adapter has begun receiving PCCC Control messages (the PCCC Control Timeout
was previously set to a non-zero value).
41 PCCC IO Timeout The adapter has not received a PCCC Control message for longer than the PCCC Control
Timeout.
42 Msg Ctrl Open The timeout attribute in either the CIP Register or Assembly object was written with a
non-zero value, allowing control messages to be sent to the adapter.
43 Msg Ctrl Close The timeout attribute in either the CIP Register or Assembly object was written with a
zero value, disallowing control messages to be sent to the adapter.
44 Msg Ctrl Timeout The timeout attribute in either the CIP Register or Assembly object elapsed between
accesses of those objects.
45...54 Reserved –
55 BOOTP Response The adapter has received a response to its BOOTP request.
56...57 Reserved –
58 Module Defaulted The adapter has been set to factory defaults.
59 FPGA Fact Load The adapter has loaded the factory configuration into its FPGA.
60 FPGA User Load The adapter has loaded the user configuration into its FPGA.
61 Net Link 1 Up A network link was available for the adapter on its Ethernet network port 1 (ENET1).
Adapter Events
Code Event Description
