Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013

161

Glossary

The following terms and abbreviations are used throughout this manual.For
definitions of terms not listed here, see the Allen-Bradley Industrial Automation
Glossary, publication

AG-7.1

.

Adapter

Devices such as drives, controllers, and computers usually require an adapter to
provide a communication interface between them and a network such as
EtherNet/IP. An adapter reads data on the network and transmits it to the
connected device. It also reads data in the device and transmits it to the network.

The EtherNet/IP Device Level Ring (DLR) adapter connects its
PowerFlex 520-series drive to an EtherNet/IP network. Adapters are sometimes
also called “cards,” “embedded communication options,” “gateways,” “modules,”
and “peripherals.”

ADC (Automatic Device Configura-

tion)

An RSLogix 5000 (version 20) and Logix Designer (version 21 or greater)
software feature that supports the automatic download of configuration data
upon the Logix controller establishing an EtherNet/IP network connection to a
PowerFlex 520-series drive and its associated peripherals.

BootP (Bootstrap Protocol)

BootP lets the adapter configure itself dynamically at boot time if the network
has a BootP server. The BootP server assigns the adapter a preconfigured IP
address, a subnet mask, and a gateway address; therefore, you do not have to
configure these using the parameters in the adapter. BootP can make it easier to
administer an Ethernet network. A free version of Rockwell Software’s BootP
Server can be accessed at

http://www.ab.com/networks

.

Bridge

A network device that can route messages from one network to another. A bridge
also refers to a communications module in a ControlLogix or CompactLogix
controller that connects the controller to a network. See also Scanner.

CIP (Common Industrial Protocol)

CIP is the transport and application layer protocol used for messaging over
EtherNet/IP, ControlNet, and DeviceNet networks. The protocol is used for
implicit messaging (real-time I/O) and explicit messaging (configuration, data
collection, and diagnostics).

ControlFLASH

An Allen-Bradley software tool that lets users electronically update firmware on
printed circuit boards.

Controller

A controller, also called programmable logic controller, is a solid-state control
system that has a user-programmable memory for storage of instructions to
implement specific functions such as I/O control, logic, timing, counting, report
generation, communication, arithmetic, and data file manipulation. A controller
consists of a central processor, input/output interface, and memory. See also
Scanner.
