TCP/IP Interface Object

Class Code

Services

Instances

The adapter supports one instance of the TCP/IP Interface object.

Class Attributes

Instance Attributes

Hexadecimal

Decimal

0xF5

245

Implemented for:

Service Code

Class

Instance

Service Name

0x0E

Yes

Yes

Get_Attribute_Single

0x10

No

Yes

Set_Attribute_Single

Number

Description

0

Class Attribute

1

Object Attribute

Attribute ID

Access Rule

Name

Data Type

Description

1

Get

Class Revision

UINT

The revision of this object

Attribute ID

Access Rule

Name

Data Type

Description

1

Get

Status of TCP/IP Network Interface

UDINT

Bit | Value
0…3 = Configuration status

0 = Not configured
1 = Configured using BOOTP, DHCP, or parameters
2 = Configured using Node Address switches
3…15 = Reserved

4 = Reserved
5 = Configuration pending
6 = Duplicate IP address
7…15 = Reserved

2

Get

Configuration Capability

UDINT

Bit | Value (0 = False, 1 = True)
0 = Supports BOOTP
1 = DNS Client (able to resolve host names by query to DNS server)
2 = DHCP Client (able to obtain network configuration through DHCP)
3 = DHCP-DNS Update (able to send its host name in the DHCP request)
4 = Configuration Settable (able to set the network configuration using TCP/

IP object)

5 = Hardware Configurable (able to set the network configuration using the

Node Address switches)

6 = Configuration change requires reset
7 = Address Conflict Detection (ACD) capable
8…31 = Reserved
