Rockwell Automation Publication 520COM-UM003A-EN-E - June 2013

123

Appendix

A

Specifications

Appendix A presents the specifications for the adapter.

Communication

Electrical

Mechanical

Environmental

Regulatory Compliance

See the PowerFlex 525 Adjustable Frequency AC Drive User Manual,
publication

520-UM001

for regulatory compliance information.

Network

Protocol
Data Rates

EtherNet/IP
10 Mbps Full Duplex, 10 Mbps Half Duplex, 100 Mbps Full Duplex or 100 Mbps
Half Duplex

Connection Limit

30 TCP connections
16 simultaneous CIP explicit messaging connections plus 1 exclusive-owner I/O
connection
The following activities use a CIP connection:
Class I I/O connections (for example, from a ControlLogix or CompactLogix

controller)

Explicit messaging where “connected” is chosen (for example, in a check box

in RSLogix 5000 or Logix Designer)

The following activities DO NOT use a CIP connection:
Explicit messaging-based control using PCCC or the Register or Assembly

objects, including the MicroLogix 1100/1400 examples in Chapter 4

Explicit messaging where “connected” is NOT chosen, which is typically the

default

Requested Packet Interval (RPI)

2 ms minimum

Packet Rate

Up to 1000 total I/O packets per second (500 in and 500 out)

Consumption

Drive
Network

250 mA @ 14V DC supplied by the host drive
None

Dimensions

Height
Length
Width

21 mm (0.83 in.)
131.0 mm (5.15 in.)
48.4 mm (1.9 in.)

Weight

44 g (1.55 oz.)

Temperature

Operating
Storage

-10...50

°

C (14...149

°

F)

-40...85

°

C (-40...185

°

F)

Relative Humidity

-5...95% noncondensing
