Appendix B
Adapter Parameters
06
07
08
09
[IP Addr Cfg 1]
[IP Addr Cfg 2]
[IP Addr Cfg 3]
[IP Addr Cfg 4]
Sets the IP address octets for the adapter’s network address
when Device parameter 05 [Net Addr Sel] is set to 1
“Parameters” and the Node Address switches (see
Node Address Switches on page 18
) are set to any value other
than (001…254) or 888.
Default:
0
Default:
0
Default:
0
Default:
0
Minimum:
0
Maximum:
255
Type:
Read/Write
Reset Required:
Yes
10
11
12
13
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
Sets the Subnet mask octets for the adapter’s network mask
when Device parameter 05 [Net Addr Sel] is set to 1
“Parameters” and the Node Address switches (see
Node Address Switches on page 18
) are set to any value other
than (001…254) or 888.
Default:
0
Default:
0
Default:
0
Default:
0
Minimum:
0
Maximum:
255
Type:
Read/Write
Reset Required:
Yes
14
15
16
17
[Gateway Cfg 1]
[Gateway Cfg 2]
[Gateway Cfg 3]
[Gateway Cfg 4]
Sets the Gateway address octets for the adapter’s local network
when Device parameter 05 [Net Addr Sel] is set to 1
“Parameters” and the Node Address switches (see
Node Address Switches on page 18
) are set to any value other
than (001…254) or 888.
Default:
0
Default:
0
Default:
0
Default:
0
Minimum:
0
Maximum:
255
Type:
Read/Write
Reset Required:
Yes
18
[Net Rate Cfg 1]
Sets the speed (10, 100) and duplex (Full, Half) at which the
adapter communicates on its Ethernet network port 1 (ENET1).
Updates Device parameter 19 [Net Rate Act 1] after a reset.
Default:
0 = Autodetect
Values:
0 = Autodetect
1 = 10Mbps Full
2 = 10Mbps Half
3 = 100Mbps Full
4 = 100Mbps Half
Type:
Read/Write
Reset Required:
Yes
Parameter
No.
Name and Description
Details
192.168.1.62
[IP Addr Cfg 1]
[IP Addr Cfg 2]
[IP Addr Cfg 3]
[IP Addr Cfg 4]
255.255.255.0
[Subnet Cfg 1]
[Subnet Cfg 2]
[Subnet Cfg 3]
[Subnet Cfg 4]
192.168.1.1
[Gateway Cfg 1]
[Gateway Cfg 2]
[Gateway Cfg 3]
[Gateway Cfg 4]
