About this documentation
Document history
1

8 EDS84ASC552 EN 9.1
1 About this documentation
Contents
The hardware manual provides the complete information on the application as directed of
the 8400 controllers of the StateLine C, HighLine C, and TopLine C versions.
Validity
Type Type designation from hardware
version
from software version
8400 StateLine C E84AVSCxxxxx VA 01.00
8400 HighLine C E84AVHCxxxxx VA 01.00
8400 TopLine C E84AVTCxxxxx VA 01.00
Target group
This Hardware Manual is intended for all persons who design, install, commission, and
adjust controllers of the 8400 Inverter Drives product range.

Tip!
Information and auxiliary devices related to the Lenze products can be found
in the download area at
http://www.Lenze.com
1.1 Document history
Material number Version Description
.Nhy 9.1 03/2014 TD14 Information on safety engineering: HW revision 2A
13418876 9.0 12/2012 TD15 Error corrections
13394172 8.1 11/2011 TD14 Changed dimension sheets
Error corrections
13385308 7.1 08/2011 TD14 Error corrections
13353079 7.0 11/2010 TD03 added:
 Devices of size 7 (30 ... 45 kW)
 Devices of the TopLine version
Error corrections
13321942 6.0 12/2009 TD03 Supplemented by devices of device size 6
(18.5 ... 22kW)
Error corrections
13296844 5.0 04/2009 TD03 Supplemented by push-through and cold plate
technique for devices of device size 5
13277975 4.0 11/2008 TD03 Supplemented by devices of device size 5 (7 ... 15kW)
13261567 3.0 07/2008 TD03 Supplemented by devices in the HighLineversion
13255657 2.1 06/2008 TD03 Supplements to the chapter ”Electrical installation”
13252301 2.0 04/2008 TD03 Complete revision
13234980 1.0 10/2007 TD15 First edition
