3.5 Product key
E84 A V xx x xxx x x x x
Product range
Inverter Drives 8400
Version
A = 1. version
Inverter type
V = vector-controlled inverter
Version
SC = StateLine C
HC = HighLine C
TC = TopLine C
Mounting type
E = installation
D = push-through technique
C = cold plate technology
Power e.g.
251 = 25 x 10 1 W = 0.25 kW
222 = 22 x 10 2 W = 2.2 kW
Voltage class
2 = 230/240 V, 1/N/PE AC (0.25 ... 2.2 kW)
4 = 400/500 V, 3/PE AC (0.37 ... 45 kW)
Ambient conditions
S = standard industrial environment IE33 according to IEC 60721-3-3
standard
V = rough environment (coated printed circuit boards)
Safety system
X = without safety system
B = with integrated safety system ”Safe torque off (STO)”
Special design
0 = without (standard)
S = reduced device dimension - ”Slim”
The nameplate serves to identify delivered products by nameplate data. The product catalogue provides
information on the possible configuration to order the products.
