Technical data
Rated data
Operation with increased power at a 230 V mains
4
55
EDS84ASC552 EN 9.1
Assignment of external mains chokes
Assignment
Type
Mains choke required
Mains choke
E84AVxxx2512
no
ELN1-0900H005
E84AVxxx3712
yes
ELN1-0900H005
E84AVxxx5512
no
ELN1-0500H009
E84AVxxx7512
yes
ELN1-0500H009
E84AVxxx1122
no
ELN1-0250H018
E84AVxxx1522
yes
ELN1-0250H018
E84AVxxx2222
-
-
Switching frequency-dependent output currents
Output currents [A] at switching frequency
2 kHz
4 kHz
8 kHz
16 kHz
Type
I
arated2
I
aM2
I
arated4
I
aM4
I
arated8
I
aM8
I
arated16
I
aM16
E84AVxxx2512
2.1
3.4
2.1
3.4
-
-
-
-
E84AVxxx3712
2.9
4.8
2.9
4.8
-
-
-
-
E84AVxxx5512
3.6
6.0
3.6
6.0
-
-
-
-
E84AVxxx7512
4.8
8.0
4.8
8.0
-
-
-
-
E84AVxxx1122
6.8
11.0
6.8
11.0
-
-
-
-
E84AVxxx1522
8.4
14.0
8.4
14.0
-
-
-
-
E84AVxxx2222
-
-
-
-
-
-
-
-
