Technical data
Current characteristics
4
69
EDS84ASC552 EN 9.1
Maximum output currents [A]
1)
at a fixed switching frequency and U
LN
= 400V
2 kHz
4 kHz
8 kHz
16 kHz
Type
I
aM02
I
aM2
I
aM04
I
aM4
I
aM08
I
aM8
I
aM016
I
aM16
E84AVxxx3714
2.6
2.6
2.6
2.6
1.5
2.6
1.0
2.1
E84AVxxx5514
3.6
3.6
3.6
3.6
2.1
3.6
1.4
3.0
E84AVxxx7514
4.8
4.8
4.8
4.8
2.8
4.8
1.8
4.0
E84AVxxx1124
4.8
6.4
4.8
6.4
3.4
6.4
2.1
5.3
E84AVxxx1524
5.9
7.8
5.9
7.8
4.1
7.8
2.5
6.4
E84AVxxx2224
8.4
11.2
8.4
11.2
5.9
11.2
3.6
9.2
E84AVxxx3024xxS
11.0
14.6
11.0
14.6
9.5
14.6
5.5
9.5
E84AVxxx3024xx0
11.0
14.6
11.0
14.6
9.5
14.6
5.5
9.5
E84AVxxx4024
14.3
19.0
13.8
19.0
9.5
17.1
5.7
9.5
E84AVxxx5524
19.5
26.0
16.9
26.0
11.7
19.5
6.5
11.7
E84AVxxx7524
24.8
33.0
24.8
33.0
16.5
26.4
9.9
16.5
E84AVxxx1134
35.3
47.0
31.7
47.0
21.2
32.9
12.9
21.2
E84AVxxx1534
48.0
64.0
44.8
62.4
30.4
43.2
17.6
27.2
E84AVxxx1834
58.5
78.0
58.5
78.0
48.8
72.2
29.3
48.8
E84AVxxx2234
70.5
89.3
68.2
89.3
49.4
75.2
30.6
49.4
E84AVxxx3034
82.6
112.1
67.9
88.5
53.1
73.8
38.4
53.1
E84AVxxx3734
108.0
136.8
93.6
115.2
79.2
97.2
54.0
72.0
E84AVxxx4534
133.5
169.1
124.6
146.9
97.9
120.2
66.8
84.6
Maximum output currents [A]
1)
at a fixed switching frequency and U
LN
= 500V
2 kHz
4 kHz
8 kHz
16 kHz
Type
I
aM02
I
aM2
I
aM04
I
aM4
I
aM08
I
aM8
I
aM016
I
aM16
E84AVxxx3714
2.6
2.6
2.4
2.6
1.2
2.4
0.7
1.7
E84AVxxx5514
3.6
3.6
3.3
3.6
1.6
3.3
1.0
2.3
E84AVxxx7514
4.8
4.8
4.4
4.8
2.1
4.4
1.4
3.1
E84AVxxx1124
4.8
6.4
4.8
6.4
2.6
5.9
1.6
4.1
E84AVxxx1524
5.9
7.8
5.9
7.2
3.2
7.2
1.9
5.0
E84AVxxx2224
8.4
11.2
8.4
11.2
4.5
10.4
2.7
7.2
E84AVxxx3024xxS
11.0
14.6
10.6
13.5
7.4
13.5
4.2
7.4
E84AVxxx3024xx0
11.0
14.6
10.6
13.5
7.4
13.5
4.2
7.4
E84AVxxx4024
14.3
19.0
10.7
17.6
7.3
13.4
4.3
7.3
E84AVxxx5524
19.5
26.0
13.1
24.1
9.0
15.2
4.8
9.0
E84AVxxx7524
24.8
33.0
19.3
30.5
12.7
20.6
7.4
12.7
E84AVxxx1134
35.3
47.0
24.7
43.5
16.2
25.6
9.6
16.2
E84AVxxx1534
48.0
64.0
34.9
49.0
23.4
33.6
13.1
20.8
E84AVxxx1834
58.5
78.0
56.2
78.0
41.1
61.2
24.3
41.1
E84AVxxx2234
70.5
89.3
57.6
89.3
41.5
63.7
25.3
41.5
E84AVxxx3034
82.6
112.1
57.1
74.9
44.4
62.2
31.7
44.4
E84AVxxx3734
108.0
136.8
79.0
97.6
66.6
82.1
44.9
60.4
E84AVxxx4534
133.5
169.1
105.3
124.4
82.3
101.5
55.5
70.8
1)
The shown values apply to the operation with ambient temperatures of up to +45°C for 2/4kHz and up to +40°C for
8/16kHz. For ambient temperatures between +40/45°C and +55°C, a derating from 2.5 %/K to the given values must
be observed.
