Product description
Device features
3

19 EDS84ASC552 EN 9.1
3 Product description
3.1 Device features
Version
Features StateLine C HighLine C TopLine C
Power range from 250 W to 45 kW   
Communication and diagnostic interfaces   
Integrated interference suppression acc. to EN 61800-3   
Integrated DC-bus connection for devices with 400 V
mains connection
  
Flying restart circuit   
Integrated brake management   
Integrated brake chopper   
Optionally: Integrated safety system ”Safe torque off
(STO)”
  
Operating modes:
VFCplus: V/f open loop control, linear and quadratic   
VFCplus: Freely definable characteristic   
VFCplus eco: Energy-efficient V/f characteristic -  
SLVC: Sensorless vector control (torque / speed)   
VFCplus: V/f closed loop control for speed-controlled
applications
  
SC: Servo control ASM (torque / speed) -  
SC: Servo control PSM (torque / speed) -  
SL PSM: Sensorless synchronous control (torque /
speed)
-  
S-shaped ramps for almost jerk-free acceleration and
deceleration
  
200 % overload current (3 s)   
IT system usability   
Protection against restart for cyclic mains switching   
CANopen baud rate Up to
1000 kbps Up to 1000 kbps
Up to 1000 kbps
Speed feedback
Incremental HTL encoder
Evaluation: Single-track / two-track
10 kHz
10 kHz and
200 kHz
10 kHz and
200 kHz
Incremental TTL encoder - - 
SSI - - 
1 V
SS
sin/cos encoder - - 
1 V
SS
sin/cos absolute value encoder (Hiperface) - - 
Applications
Actuating drive   
Table positioning -  
Switch-off positioning   
Touch probe -  
Axis bus - - 
Digital frequency coupling - - 
Digital 2.5 A output with integrated spark suppressor,
e.g. for the direct control of a 24 V motor holding brake
-  
