Mechanical installation
Standard devices in the power range 3 ... 22 kW
Assembly in push-through technique (thermal separation)
5
121
EDS84ASC552 EN 9.1
5.3.2
Assembly in push-through technique (thermal separation)
The E84AVxxD... controllers are designed for mounting in push-through design. The scope
of supply includes all parts required for mounting.
Installation steps
How to proceed:
1. Prepare mounting cutout and mounting holes (threaded holes M5 recommended).
2. Insert the 8400 frequency inverter into the mounting cutout.
3. Tighten with 6 screw and washer assemblies M5 x 10 (cross screw connection
recommended).
4. Seal the screws to ensure the IP54 enclosure or UL type 12.
StateLine, HighLine
8400GG106e
Fig. 5-25
Device dimensions
h
b
t
h
1
h
2
b
1
t
1
t
3
g
1
g
2
[kW]
[mm]
E84AVxxD3024xXx
3
270
174
141
318
366
140
128
64
6
5
E84AVxxD4024xXx
4
E84AVxxD5524xXx
5.5
E84AVxxD3024xBx
3
270
174
161
318
366
140
148
64
6
5
E84AVxxD4024xBx
4
E84AVxxD5524xBx
5.5
