Mechanical installation
Standard devices in a power range of 0.25 ... 3 kW
Mounting in ”cold plate” technique
5
105
EDS84ASC552 EN 9.1
StateLine, HighLine
8400GG105a
Fig. 5-12
Dimensions for mounting
d
1
d
2
d
3
d
4
c
c
1
c
2
c
3
i
j
11
j
21
[kW]
[mm]
[kg]
E84AVxxC2512xX0
0.25
10
10
85
80
12
6
6
90
0
> 95 > 95
1.3
E84AVxxC3712xX0
0.37
E84AVxxC3714xX0
0.37
8.5
12.5 110 105
12
6
6
90
0
> 95 > 95
1.5
E84AVxxC551xxX0
0.55
E84AVxxC751xxX0
0.75
E84AVxxC112xxX0
1.1
12.5 12.5 135 135
12
6
6
125
0
> 95 > 95
2.0
E84AVxxC152xxX0
1.5
E84AVxxC222xxX0
2.2
E84AVxxC2512xB0
0.25
10
10
85
80
12
6
6
90
0
> 95 > 95
1.4
E84AVxxC3712xB0
0.37
E84AVxxC3714xB0
0.37
8.5
12.5 110 105
12
6
6
90
0
> 95 > 95
1.6
E84AVxxC551xxB0
0.55
E84AVxxC751xxB0
0.75
E84AVxxC112xxB0
1.1
12.5 12.5 135 135
12
6
6
125
0
> 95 > 95
2.1
E84AVxxC152xxB0
1.5
E84AVxxC222xxB0
2.2
