Mechanical installation
Standard devices in a power range of 30 ... 45 kW
Mounting in ”cold plate” technique
5

151 EDS84ASC552 EN 9.1
TopLine
8400GG108c
Fig. 5-47 Device dimensions
h b t h
1
h
2
t
1
t
2
g
1
g
2
g
3
[kW] [mm]
E84AVTCC3034xXx 30
450 250 199 520 636 186 225 8.5 16 18 E84AVTCC3734xXx 37
E84AVTCC4534xXx 45
E84AVTCC3034xBx 30
450 250 219 520 636 206 245 8.5 16 18 E84AVTCC3734xBx 37
E84AVTCC4534xBx 45
