Technical data
Rated data
Overview
4
33
EDS84ASC552 EN 9.1
4.2
Rated data
4.2.1
Overview
Input data
Basis of the data
Mains
Voltage
Voltage range
Frequency range
U
Lrated
[V]
U
Lrated
[V]
f [Hz]
1/N/PE AC
230
180 - 0 % ... 264 + 0 %
45 - 0 % ... 65 + 0 %
3/PE AC
400
320 - 0 % ... 440 + 0 %
45 - 0 % ... 65 + 0 %
3/PE AC
500
400 - 0 % ... 550 + 0 %
45 - 0 % ... 65 + 0 %
Voltage
Frequency
Rated current [A]
Number of
phases
[V]
[Hz]
up to +45 °C
up to +55 °C
E84AVxxx2512
230
50/60
3.4
2.6
1
E84AVxxx3712
230
50/60
5.0
3.8
1
E84AVxxx5512
230
50/60
5.3
4.0
1
E84AVxxx7512
230
50/60
8.0
6.0
1
E84AVxxx1122
230
50/60
12.0
9.0
1
E84AVxxx1522
230
50/60
13.7
10.3
1
E84AVxxx2222
230
50/60
21.8
16.4
1
E84AVxxx3714
400/500
50/60
1.8/1.4
1.4/1.1
3
E84AVxxx5514
400/500
50/60
2.7/2.2
2.0/1.7
3
E84AVxxx7514
400/500
50/60
3.6/2.9
2.7/2.2
3
E84AVxxx1124
400/500
50/60
4.4/3.6
3.3/2.7
3
E84AVxxx1524
400/500
50/60
5.5/4.4
4.1/3.3
3
E84AVxxx2224
400/500
50/60
7.3/5.8
5.5/4.4
3
E84AVxxx3024xxS
400/500
50/60
9.8/7.8
7.4/5.9
3
E84AVxxx3024xx0
400/500
50/60
9.8/7.8
7.4/5.9
3
E84AVxxx4024
400/500
50/60
13.1/10.5
9.8/7.8
3
E84AVxxx5524
400/500
50/60
18/14.4
13.5/10.8
3
E84AVxxx7524
400/500
50/60
20.0/16.0
15.0/12.0
3
E84AVxxx1134
400/500
50/60
29.0/23.2
21.7/17.4
3
E84AVxxx1534
400/500
50/60
29.0
1)
/23.2
1)
21.4
1)
/17.4
1)
3
E84AVxxx1834
400/500
50/60
36.0/31.0
27.0/23.3
3
E84AVxxx2234
400/500
50/60
42.0
1)
/36.1
1)
31.5
1)
/27.1
1)
3
E84AVxxx3034
400/500
50/60
55.0
1)
/46.9
1)
41.3
1)
/35.2
1)
3
E84AVxxx3734
400/500
50/60
68.0
1)
/58.2
1)
51.0
1)
/43.7
1)
3
E84AVxxx4534
400/500
50/60
80.0
1)
/69.2
1)
60.0
1)
/51.9
1)
3
Ambient temperature in the control cabinet, switching frequency 2 and 4 kHz, operation without mains choke
1)
only with external mains choke
