62 Instructions for Use V 2.2 RevI – 08/2013
Functions of the touchscreen
(continued)
Fig. 67
The SMART FUNCTIONS menu
active not active

To switch to the SMART FUNCTIONS
window, press the SMART SCREEN
button.
Before starting an operation, you first have to select the stations (system bottles
and RTU-bottles) to be used.
To select a station for a function, activate the corresponding symbol by touching it
on the touchscreen (
Fig. 68 ).
Activated symbols are surrounded by a red border.
Touch the symbol a second time to disable the station.
The stations (system bottles and RTU-
bottles) are displayed in the order in
which they are positioned in the re-
agent cabinet and in the drawer of the
ASP6025.
If a station contains a reagent for which the threshold value has been exceeded in
the RMS, this is flagged on the SMART SCREEN with an exclamation mark (
Fig. 69 )
Fig. 68
Fig. 69
4. Initial Operation
If a station or container cannot be selected for activation, the
reason for this is explained in a dialog window.
