4.
Initial Operation
Fig. 30
41
42
Attach the magnetic stirrer (41) to the axis
on the floor of the retort with the little hole
facing upwards.
Insert the sieve (42) into the drain opening on
the floor of the retort.
Every time a program is started (except in CONCENTRATION
mode, see
Chapter 5.1.2
), a message is first displayed in which
the start must be confirmed.
Depending on how many baskets the retort is loaded with, the
fill volume can be selected in the dialog box by pressing the
corresponding button (
Fig. 31
).
• For this purpose, there are three level sensors (40.
1
- 40.
3
)
(
Fig. 31
) located behind the cover (40) in the back panel of
the retort.
• The uppermost sensor (40.
4
) prevents the retort from being
overfilled or overflowing.
40.
1
40.
2
40.
3
40.
4
The retort
(continued)
Filling the retort up to sensor 40.
1
Filling the retort up to sensor 40.
2
Filling the retort up to sensor 40.
3
Level sensors (
at left in Fig. 31
)
Fig. 31
Selection
buttons
Fill level
sensors
40
It is imperative to insert the mag-
netic stirrer before an infiltration
program is started!
