53 Leica ASP6025
Labels for RTU-bottles ( Fig. 56 )
10
Fig. 56
The labels for the RTU-bottles in the drawer come in the same
eight colors as for the system bottles.
The label has filling level marks for the RTU-bottles printed on it,
therefore it must be applied with particular care.
Fig. 57
73
Detail 1
Detail 2
4. Instrument Setup
To ensure that the filling level marks are valid, apply the narrow
side of the label exactly at the point on the RTU-bottle (10)
where the bottleneck ends (Detail 1 in
Fig. 57 ) then press it on
vertically from top to bottom.
The symbol at 5 l (Detail 2 in
Fig. 57 ) means that the RTU-
bottle must be filled up to that point if the retort is to be filled
up to the third level sensor (corresponds to loading with three
baskets).
Accordingly, the symbols at 3.8 l indicate the fill volume for
filling the retorts up to the second level sensor.
The station number can likewise be noted on the label as well
as the date when the specified reagent was commissioned
( Fig. 57 ).
This must also be adjusted in the reagent status for a
newly filled RTU-bottle.
Caution!
The specified filling level marks (5.0 l and
3.8 l) are valid only for the RTU-bottles includ-
ed in the delivery package. If other contain-
ers are used, the specified fill volumes on the
label will not agree.
