Leica Biosystems ASP6025 - Manual (Page 31)

29 Leica ASP6025
4. Instrument Setup
Fig. 6
Fig. 7
89
88
90
86
85
87
Removing the transport anchors
Unpacking the instrument
(continued)
• First, remove the additional RTU-bottle (10) out of the
transport anchor.
• Take out the two transport anchors (86) made of foam
( Fig. 6 ).
• Afterwards, the outer sleeve of the packaging (85) must be
removed from the pallet (87) by pulling it upwards.
Unpacking and removing the accessories
• The carton (89) contains the accessories that are not yet
installed in the instrument.
Carefully set the carton aside.
• Then remove the rest of the molded foam material (90) on
the front side of the pallet ( Fig. 7 ).
• Then, carefully remove the plastic dust cover (88) from the
instrument.
10
Before unpacking the instrument, be abso-
lutely certain to read the unpacking instruc-
tions. They are attached to the outside of the
transport packaging.
