30 Instructions for Use V 2.2 RevI – 08/2013
4. Initial Operation
Setting up the ramp Unpacking the instrument
(continued)
Fig. 8
93
92
94
91
91
• Pull out the two rails (91)
for the ramp beneath the
instrument by pulling
them forwards (
Fig. 8 ).
91
• Hook these rails on the left
and right with the panel
(92) into the groove (93)
of the pallet so that they
are flush with the wooden
board (94) that holds the
instrument (
Fig. 9 ).
95
95
Fig. 10
Fig. 9
• While doing so, make sure that the plate (92) is between the
two screws (95) in the groove. These screws prevent the rail
from being able to shift laterally.
97 96
• To do so, the lever must be folded upwards.
• Now release the brake lever
(97) on the two front transport
castors (96) so that the instru-
ment can be moved ( Fig. 10 ).
