4.3.3 Go to View
Operating the scroll key whilst the ‘Go to view’ item is highlighted, calls the Go to view submenu (figure
1.3.3a). This allows the user to view channel alarms, system alarms, messages or to select a different
display mode.
Figure 1.3.3a Go to view submenu
Notes:
1. If an option (e.g. ‘Steriliser’) is not fitted, its display mode does not appear in the list.
2. Some display modes must be enabled in Instrument. View configuration before they become
available.
Alarm Summary
System Alarms
Message Summary
Vertical Trend
Horizontal Trend
Vertical Bargraph
Horizontal
Bargraph
Numeric
Alarm Summary
Vertical Trend
Alarm Panel
Control
Control (Dual Loop)
Cascde
Programmer
Steriliser
Promote List
Modbus Master
EtherNet/IP
Alarm Panel
Control
Dual Loop
Cascade
Steriliser
Promote List
Modbus Maste
r
EtherNet/IP
