4.12.8 Using the Character Parity Mode dropdown list
Use this option to customize the Encoding Mode (used to encode the magnetic data on the
currently selected track).
Step Procedure
1 Select
No Parity to change the Character Parity to none.
OR
Select
Even Parity to change the Character Parity to Even Parity.
OR
Select
Odd Parity to change the Character Parity to Odd Parity. (Note: This is the default for all
tracks.)
4.12.9 Reviewing the ISO Track Locations
The magnetic Encoding Module encodes onto tracks in accordance with an ISO 7811-2
Magnetic Stripe.
TRACK1 0.110"
TRACK2 0.110"
TRACK3 0.110"
0.130"
0.140"
0.223" 0.353" 0.493"
