Allied Telesyn AT-VIEW PLUS
DEVICE MANAGEMENT
Note - AT-View Plus Device Manager allows the user to enter up to 63 characters for the
Identity and Secret parameters. Entering more than 63 characters will result in the error
message: "The error occurred with 'Set' operation. Error: bad value."
Note - Security Secrets parameters return to their default values whenever the device is
restarted.
Note - The current firmware version does not allow the Direction parameter to be
configured. Attempting to configure this parameter will result in the error message: "The
error occurred with 'Set' operation. Error: bad value."
Port Menu
From the Port menu, you can view and edit MIB information about selected ports.
Interface Info
Displays port statistics such as the number of frames received and transmitted on the port,
bytes received and transmitted on the port, and port status.
Note - The Interface Info sub-menu option displays port parameters for 20 ports. By
default, the Administration Status parameter is set to 'up' for the first four ports and 'down'
for the rest of the ports. For ports 1 to 3, the Administration Status parameter cannot be
configured. Its value is fixed to 'up'. For ports 5 to 12, valid MIB Set values for the
Administration Status parameter are 'up' and 'down'. Attempting to set this parameter to
any other value will result in the error message: "The error occurred with 'Set' operation.
Error: bad value."
Note - The Administration Status parameter always returns to its default value whenever
the device is restarted.
Error Statistics
Displays error statistics for the port.
Note - The current firmware version returns 'noSuchName' for the Ethernet Chip Set
parameter.
AT-AR200E
PN 613-50665-00 Rev C Page 97 of 294
